Warn 9.0Rc
Rock Crawling Winch
Information and
specifications from the Warn website
|
|
NEW! WARN 9.0Rc
Rock Crawling Winch |
Competitive
rock crawling means tackling tough climbs
and tight turns. That's why rock crawling
rigs need a low-profile, lightweight winch
like the WARN 9.0Rc that delivers maximum
power in a compact, 54-lb. unit.
Like its professional counterpart, the 9.0R,
the 9.0Rc is a short-drum, 9,000 lb.
capacity winch that features a 4.8 hp Series
Wound Motor for fast line speeds. An
exclusive, multi-segment Cam Actuated Brake
gives positive operator control during
winching.
The 9.0Rc comes standard with 50' of 3/8"
diameter synthetic rope. Other features
include: a chromate undercoating and gloss
red paint that provide superior corrosion
resistance; a rugged, 360-degree swivel hook
and thimble; an aluminum hawse fairlead;
extreme duty winch sealing; and a "Ballistic
Nylon" Sliding Sleeve that provides extra
protection against abrasion and wear.
The 9.0Rc - a winch built for rock crawlers
looking for efficiency, reliability and the
legendary WARN performance.
|
|
9.0Rc
SPECS/PART NUMBER |
|
Part Number: 71550 |
|
Rated Line Pull: 9000
lbs. (4080 kgs.) single-line |
|
Motor: Series
Wound, 12V 4.8 hp |
|
Remote Control: Remote
switch, 12' (3.7m) lead |
|
Geartrain: 3-Stage
Planetary |
|
Gear Ratio: 216:1 |
|
Lubrication: Aeroshell
#17 |
|
Clutch (freespooling): Sliding
Ring Gear |
|
Brake: Automatic
Direct Drive Cone |
|
Drum
Diameter/Length: 2.75"/4.75"
(7.0cm/12cm) |
|
Weight: 54
lbs. (24.8 kgs) |
|
Rope: 50',
3/8" Synthetic Rope |
|
Fairlead: Polished
Aluminum Hawse |
|
Recommended Battery: 650
CCA minimum for winching |
|
Battery Leads: 2
gauge, 72" (1.83m) |
|
Finish: Chromate
with high-gloss red paint |
|
Nuts/Bolts: PN
39625 |
|
|
PERFORMANCE SPECIFICATIONS |
Line
Pull
Lbs.(Kgs.) |
Line
Speed
FT./min(M/min.) |
Motor
Current |
Pull by
layer
layer/Lbs(Kgs.) |
| 0 |
42
(12.8) |
80
amps |
1/900 (4082) |
| 2000 |
16
(4.88) |
200
amps |
2/7280 (3302) |
| 4000 |
11.9
(3.63) |
285
amps |
3/6670 (3026) |
| 6000 |
9.79
(2.98) |
350
amps |
4/6230 (2826) |
| 8000 |
8.01
(2.44) |
435
amps |
|
| 9000 |
6.4
(1.94) |
465
amps |
|
|
| |
| Above
performance specs are based on first layer
of drum |
|
|
|
|
